APT-5 "Carpet IV" Radar Jammer
This was a set designed to replace the AN/APT-2 with more power and a wider bandwidth. It covered a band of 350-1,200MHz with a power output of 15 watts.

T-85/APT-5 Jammer

Overall APT-5 Jammer System

APT-5 Jammer Schematic
